As shown on the diagram, the vertical flooded heat exchanger design eliminates the need for a pressure reducing station, relief valves, steam control valves, flash tank, or condensate lift pumps.

Rather than controlling steam flow to maintain the process setpoint, Maxi-therm’s design controls the condensate level within the heat exchanger using a small liquid control valve. By sub-cooling the condensate, flash losses are eliminated and radiation losses are reduced, resulting in a significant boost in efficiency.

All Maxi-therm systems are 100% packaged solutions including a comprehensive touchscreen control platform that is compatible with BACnet and other BMS systems. Single-point system connections are standard; field assembly is not required.

Ready to get started on your project? Contact us to get in touch with one of our sales engineers! For detailed product information, visit or contact us at Raven Supply for assistance.
